3v Lcd Graphic Display 128x64 6800 Interface ST7567S-G4 Driver

Place of Origin : Guangdong, China

Brand Name : TSD

Packaging Details : 64pcs per small box , box size is 39x17x12cm.
512pcs per carton, cartons size is 39x35x48cm, G.W. about 15kg

MOQ : Negotiable

Price : Negotiable

Type : COG LCD

Display Size : 2.2inch

Supplier Type : Manufacturer

Active Area : 46.05x23.01mm

Resolution : 128X64 dots

Viewing direction : 6 O'clock

Outline Dimension : 58.2x39x8.0mm

Driver IC : ST7567S-G4

Backlight color : White color

Driver condition : 1/65 duty, 1/9bias

LCD Type : FSTN Positive Transflective

Dots pitch : 0.36(L)*0.36(W)

Interface Type : 6800/8080

Contact Now

Transflective 3v 128x64 graphic lcd module 12864 cog lcd display fpc fstn mono lcd

About us

3v Lcd Graphic Display 128x64 6800 Interface ST7567S-G4 Driver

Display type	FSTN, positive, transflective
Part No.	TSG12864-1185-FFDLWS-R
Resolution	128xRGBx64 dots
Outline dimension	58.2x39x8.0mm
Active Area	46.05x23mm
Viewing angle	6 o'clock
Driver IC	ST7567S
Driving Method	1/65 duty, 1/9 bias
Operation temperature	-20℃ to +70℃
Storage temperature	-30℃ to +80℃

More detailed datasheet can be provided! Click here to contact us!
